1260 C Ceramic Fiber Board Refractory Fireproof High Temperature For Industrial Kiln And Furnace Kiln Lining
We offer quality control, full customization, design customization, and sample customization, holds product certifications for you all.
Leadsun ceramic fiber board is a high-quality lightweight refractory material, made from high-purity alumina silicate fibers, and is capable of withstanding continuous working temperatures up to 1430°C (2600°F).
The ceramic fiber board is manufactured through advanced vacuum molding technology. It features a uniform and sturdy structure with excellent mechanical strength. Compared to traditional ceramic fiber blankets, it can better withstand high-speed airflows. This makes it an ideal inner lining solution for high-temperature industrial equipment such as furnaces, boilers, pipes and chimneys.
Furthermore, due to the extremely low thermal conductivity and negligible thermal capacity of the ceramic fiber board, this material can significantly reduce heat loss and enhance energy efficiency. Additionally, it can accelerate heating and cooling cycles, shorten processing time, and allow for quicker access to the equipment for inspection and maintenance after operation. Its durability, thermal stability, and ease of installation also contribute to extending service life, reducing downtime, and making it suitable for demanding thermal applications.
| Item |
Common |
Standard |
H Pure |
H Alumina |
Zirconium |
| AL2O3(%) |
44 |
46 |
47-50 |
52-55 |
39-40 |
| Fe2O3(%) |
1.2 |
1 |
0.2 |
0.2 |
0.2 |
| ZrO2(%) |
－ |
－ |
－ |
－ |
15-19 |
| Classification Temperature (℃) |
1100 |
1260 |
1260 |
1360 |
1430 |
| Working Temperature (℃) |
1000 |
1050 |
1100 |
1200 |
1350 |
| Density (kg/m3) |
260/320 |
260/320 |
260/320 |
260/320 |
260/320 |
| Permanent linear shrinkage(%)(after24 hours,density 128kg/m3) |
-4 |
-3 |
-3 |
-3 |
-3 |
| (1000°C) |
(1000°C) |
(1100°C) |
(1250°C) |
(1350°C) |
| Tensile strength (Mpa) density128kg/m3) |
0.08-0.12 |
0.08-0.12 |
0.08-0.12 |
0.08-0.12 |
0.08-0.12 |
Advantages:
1. Low thermal conductivity,saves fuel
2. Very low heat storage,faster heat and cool-down reducing cycle times
3. Ligh weight.replaces heavy back-up insulation.less steel required.
4. Excellent thermal shock resistance
5. Resistant to hot gas erosion
6. Resists most chemical attacks
7. Easy to cut, handle and install
8. Low sound transmission
9. Resists penetration by molten aluminum and other non-ferrous metals
Applications
1. Refractory lining for industrial furnaces in walls,roofs,doors,stacks,etc.
2. Combustion chamber liners,boilers and heaters
3. Back-up insulation for brick and monolithic refractories
4. Transfer of molten aluminum and other non-ferrous metals
5. Expansion joint boards
6. Barrier against flame or heat
7. Hot face layer for high velocity or abrasive furnace atmosphere
